- ISUZU D-MAX TF 06/12-01/17 Space C/Chas & Pick Up
- ISUZU D-MAX TF 06/12-01/17 4Dr C/Chas & Pickup
- ISUZU D-MAX TF 02/17-07/20 Space C/Chas & Pick Up
- ISUZU D-MAX TF 02/17-07/20 4Dr C/Chas & Pick Up
- ISUZU MU-X RF 05/17-07/21
Weight | 80.000000 kg |
Length | 2070 mm |
Width | 880 mm |
Height | 740 mm |
FEATURES:
Material: | Textured Black Powdercoat Steel |
Size: | 63mm Upper Tube, 50mm Angled Lower Tube |
ADR: | Airbag Compliant. Does not void vehicle manufacturer's warranty |
Suits: | All models |
Winch: | Integrated mount rated to 9500lb/4300kg |
Recovery: | Integrated 8000kg Rated Recovery Points, Strengthened Hi Lift Jacking Points |
Indicators: | Required model dependent |
Lights: | Optional Off-road work lights (033CS89LED) Dual mounting tabs on upper hoop to mount drive lights. Suits an LED lightbar up to 900mm long underneath upper hoop |
Aerial: | Dual Aerial Tabs |
- Approximate Fitting Time: 4.5 hours
- Suggested Fitting Cost: $652.50
- Bumper cut fitment
- Chaser bar is supplied with a high-strength winch frame and dual wing guards
- 077SBFUG32P: Optional front underbody guard is recommended fitment
- Does not include Supplementary Kits required
- 076SLKIT001: Indicator Lamp required for SX & EX models
- 076SLKIT002: Park Lamp required for LS-M, LS-U, LS-T models
- 076WLKIT006: Supplementary wiring kit SX & EX models
- 076WLKIT010: Supplementary wiring kit LS-M, LS-U, LS-T 06/12-01/17 models
- 076WLKIT021: Supplementary wiring kit LS-M, LS-U, LS-T 02/17-07/20
- 033CS89LED: Optional Off-road Worklights kit
- Recommended Winches: 947TJMTQ95DAA or 947TQBK95DAA 9500lb Synthetic Rope or 947TJMTQ95S 9500lb Steel Rope
- Fitting Instructions
Suggested time for fitment and fitment costs are an approximate figure only, actual labour costs may vary. See in-store for details.
